G-401 Regular Chain Swivel Eye and Eye

G-401 Regular Chain Swivel Eye and Eye

Size	W.L.L.	Weight	Dimensions (in.)
(in.)	(lbs.)	(lbs.)	A	B	C	D	E	G	J	M	R	U	V
1/4″	850	0.13	1.25	0.69	0.75	0.62	1.12	0.25	0.69	0.31	2.25	1.69	1.25
5/16″	1250	0.25	1.63	0.81	1	0.75	1.38	0.31	0.81	0.38	2.72	2.06	1.47
3/8″	2250	0.54	2	0.94	1.25	1	1.75	0.38	1	0.5	3.44	2.5	1.88
1/2″	3600	1.12	2.5	1.31	1.5	1.25	2.25	0.5	1.31	0.63	4.25	3.19	2.44
5/8″	5200	2.09	3	1.56	1.75	1.5	2.75	0.62	1.5	0.75	5.13	3.88	2.94
3/4″	7200	3.09	3.5	1.75	2	1.75	3.25	0.75	1.88	0.88	5.78	4.94	3.46

G-401 Regular Chain Swivel Eye and Eye also called Forged Chain Swivel,Join in between your Boat Anchor and your Anchor Chain to prevent Twisting or Snagging in your line usually fitted between the anchor and the chain cable to prevent the chain cable from twisting and kinking.

G-401 Regular Swivel Manufacturer-Kailipu Professional for Rigging and Lifting.

For any more help, e-mail our specialists at [email protected] for assistance.
